2002 Yamaha WARRIOR Service and Repair Manual

A new part number takes over for the later Warriors. LIT-11616-YM-38 covers 2002 through 2004, and the 2002 machine is model code YFM350XPB.

This is a narrower book than the one that preceded it, and it no longer carries the Big Bear. If you have been working from the earlier volume, note the change; the specifications for these years live here.

Sections

• General information and periodic maintenance
• Engine and transmission service with clearances and wear limits
• Torque values and tightening sequences
• Carburetion and ignition specifications
• Electrical testing with factory readings
• Chassis: steering, suspension, wheels, brakes, final drive
• Wiring diagrams and troubleshooting

Confirm YFM350XPB against the frame before using it. Three model years in one binding is tight enough that the tables are easy to navigate, but the codes still differ and the figures follow the codes.
