2002 Yamaha RAPTOR 660 Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Four model years of the RAPTOR 660, 2002 through 2005, are documented in Yamaha LIT-11616-RP-66. The 2002 machine is model code YFM660RPL.

Owners of these quads tend to need two things from a manual: the engine specifications, since the top end and clutch see real use, and the electrical diagrams, since age takes its toll on connectors. Both are here in factory form, the first as nominal dimensions with wear limits, the second as the complete harness with circuit checks.

The rest follows the dealer structure. Periodic maintenance intervals, carburation and fuel system service, cooling, drive chain and sprocket figures, brake overhaul, steering and suspension, all with torque values at reassembly and exploded views for identification.

Confirm YFM660RPL on the frame label first.
