2002 Yamaha G16-AX "ULTIMA" (CARB) Service and Repair Manual

2002 closed out the G16 ULTIMA, and the final carburetted car is coded G16AX. Service information for it lives in LIT-19616-G1-60.

The book reaches back to 1996, so it holds the whole production span in one place along with thirteen other models. On the carb side those are the G16-AP, G16-AR, G16-AS, G16-AT, G16-AU and G16-AW; on the electric side the 36-volt G16-EP, G16-ER, G16-ES, G16-ET, G16-EU, G16-EW and G16-EX.

• Factory maintenance intervals and inspection routines
• Engine, clutch and drive overhaul in the order Yamaha specifies
• Service limits and torque values throughout
• Wiring diagrams and symptom-based diagnosis

For a car this age the specification pages tend to matter as much as the procedures, since wear is what you are measuring against. Check the plate reads G16AX.
