2000 Yamaha VENTURE 500 XL Service and Repair Manual

LIT-12618-02-03 is the Yamaha number you want if the sled in the garage is a 2000 Venture 500 XL. Its model code is VT500XLD, one letter along from the 1999 machine, and a few tables in the book turn on that difference.

Yamaha wrote the volume to serve 1999 through 2001 and added the Phazer with electric start to its coverage. Nothing about that dilutes the Venture material; it simply means shared assemblies are documented once.

Chapters move from periodic maintenance into engine work, with the clearances and torque figures the factory specifies for each fastener and bearing. Fuel and oil systems follow, then the drive clutch, chaincase and track, then chassis and suspension. The electrical chapter includes complete wiring diagrams and the resistance checks needed to condemn a coil or a switch rather than guess at it.
