2000 Yamaha G16-EU "ULTIMA" (36V - DC MOTOR) Service and Repair Manual

By 2000 the electric ULTIMA was still the same basic car, and this one is coded G16EU with its 36-volt DC motor. Service coverage: LIT-19616-G1-60.

Yamaha published a single manual for the platform, so the pages take in every model year from 1996 to 2002 and thirteen other machines. The electric line is represented by the G16-EP, G16-ER, G16-ES, G16-ET, G16-EW and G16-EX, and the carburetted line by the G16-AP through G16-AX.

• Motor, controller and charging procedures with expected readings
• Wiring diagrams as the harness was built
• Brake, steering and suspension work with factory torque values
• Inspection measurements and the limits that decide replacement

Nothing in it is generalised from another make, and the figures quoted are the ones Yamaha's engineers set when the car was new. The plate on the car settles fitment, so look for G16EU stamped on it before ordering.
