1998 Yamaha ROYAL STAR TOUR DELUXE Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Model code XVZ1300LTK, manual LIT-11616-VZ-01. That pairing is what identifies a 1998 Tour Deluxe and the book Yamaha wrote for it.

The manual's range is 1996 to 2001, and it includes the Royal Star, the Royal Star Boulevard and the Royal Star Tour Classic. Nothing about that is a shortcut; the factory grouped the XVZ1300 machines this way because the procedures genuinely carry across, and the tables handle the exceptions.

For someone doing the work, the useful contents are the tightening torques, the clearances and service limits, the sequence each assembly should be dismantled and rebuilt in, the periodic maintenance schedule, the full wiring diagrams and the symptom-led troubleshooting charts.

Check XVZ1300LTK against the code on your own frame first. On a touring bike that may have had a long and busy life, that check is worth the minute it takes.
