1996 Yamaha Phazer II Service and Repair Manual

Model code PZ480S and part number LIT-12618-PZ-50 are the two details to check against a 1996 Phazer II before ordering. The manual is Yamaha's own, and it was written to serve the entire Phazer family across a ten-year span, 1990 to 1999, including the PHAZER and the electric-start Phazer.

Working on a sled from the mid-nineties usually means dealing with parts that have already been apart once. The factory procedures help there, because they give the assembly order and the torque figures that a previous repair may not have respected, and the service limits that decide whether a component still measures up.

Also included are the carburettor and ignition settings, clutch and drive specifications, suspension adjustment, brake service and the complete wiring diagrams.
