1996 Yamaha G19-EP "ULTIMA" (48V - DC MOTOR) Service and ...
LIT-19616-G1-90 is the number to look for if the car is a 48-volt G19. This one is the 1996 G19-EP, code G19EP, the first year of the series.
Yamaha wrote the manual to last the platform's life, so it spans 1996 to 2002 and takes in the G19-ER, G19-ES, G19-ET, G19-EU and G19-EW along with the G19-AX from the final year. All six of those cars share the pages with this one.
Its strength on a 48-volt car is the electrical material: the motor and controller procedures, the charging system checks, the wiring diagrams as the harness left the factory and the sequence Yamaha specified for narrowing a fault down. Mechanical chapters handle brakes, steering, suspension and body with torque figures and wear limits.
Confirm G19EP on the code plate before ordering.
