1995 Yamaha TIMBERWOLF 4WD Service and Repair Manual

From 1995 the 4WD Timberwolf gets its own factory volume: LIT-11616-09-11, covering model years 1995 through 2000. The 1995 machine is model code YFB250FGN.

Worth knowing if you are cross-shopping manuals, since the earlier Timberwolf book carried a different part number and a different range. Match LIT-11616-09-11 to YFB250FGN and you have the right reference for this quad.

How it is arranged

• General information, then periodic inspection and adjustment
• Engine overhaul with clearances, service limits and torque sequences
• Carburetor and fuel system specifications
• Electrical testing, including ignition and charging values
• Chassis: steering, suspension, brakes, wheels and drive
• Wiring diagrams and diagnostic tables

It assumes you can turn a wrench and tells you the numbers instead of the basics. For a six-year run in one binding, that also means later-year revisions are visible in the same tables.
