1995 Yamaha G14-AM "ULTIMA" (CARB) Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Part number LIT-19616-00-70 identifies the factory manual that Yamaha wrote for the 1995 ULTIMA. The car itself is coded G14AM, and that code is what tells a carburetted G14 apart from its electric sibling.

Two model years sit inside this book, 1995 and 1996. Yamaha also folded in the G11-AP YAMAHAULER and the 36-volt DC motor cars, the G14-EM and G14-EP, so the same pages serve both the engine-driven and the electric side of that generation.

The content is dealer material rather than a general repair guide. Procedures are laid out in the order the factory expects the work to be done, with tightening values, clearances and wear limits given where a measurement decides whether a part goes back on. Wiring is drawn out circuit by circuit, and the troubleshooting sections start from the symptom the owner reports.

Match G14AM to the plate and the fitment is settled.
