1994 Chevrolet G10 Service and Repair Manual

This factory service and repair manual for the 1994 Chevrolet G10 covers two engines, a 5.0L V8 of 305 cubic inches and a 4.3L V6 of 262 cubic inches, both overhead-valve, naturally aspirated and gasoline-fed, in four bodies: standard and extended passenger vans and standard and extended cargo vans, all three-door. Beauville, Chevy and Sportvan are the trims. Engine, driveline, brake and body electrical material is arranged system by system, so a job can be looked up without reading around it.

Engines covered

• 5.0L V8 (305 cu in) — OHV, naturally aspirated, gasoline
• 4.3L V6 (262 cu in) — OHV, naturally aspirated, gasoline

Body styles covered

• 3-door standard passenger van
• 3-door extended passenger van
• 3-door van standard cargo van
• 3-door van extended cargo van

Trims covered

• Beauville
• Chevy
• Sportvan

Known issues on the 1994 G10. Three items sit on the 1994 van's federal record. Two were raised against replacement filters sold for it — a fuel filter that can seal badly and leak gasoline near an ignition source, and an oil filter that can seal badly and let the engine lose oil — both with fire as the consequence. The third is a driveability campaign for vehicles built with the fuel-injected 6.5L diesel, covering poor throttle response, stalling, misfire and hard starting hot or cold. One owner complaint, on the electrical system, is also recorded.
