1993 Yamaha VENTURE ROYALE Service and Repair Manual

XVZ1300DE closes out the Venture Royale run as the 1993 model, and it is the final year inside service manual LIT-11616-XV-14. Yamaha's coverage there starts in 1986 and includes the standard Venture.

A last-year bike is often the one people keep, and this manual is what keeps it on the road. The maintenance schedule tells you when. The procedures tell you how. The specification tables tell you whether the part you just measured is still serviceable.

Chapters cover tightening torques throughout the machine, valve clearance and carburetor adjustment, the engine taken fully apart and rebuilt, shaft final drive, air suspension service and pressures, fork and brake overhaul, and the electrical system with its diagnostic sequences and full wiring diagrams.

Order LIT-11616-XV-14 after confirming XVZ1300DE on the frame.
