1990 Yamaha VENTURE ROYALE Service and Repair Manual

Yamaha service manual LIT-11616-XV-14 reaches into the 1990s, and the Royale of 1990 is model code XVZ1300DAC. The same volume covers the Venture and the whole 1986 to 1993 span.

Fitment first

Suffix letters move every year on these bikes while the manual stays put. Read the frame plate, note XVZ1300DAC, and then order by LIT-11616-XV-14. Doing it in that order avoids buying the wrong book for a bike that was retitled or partly rebuilt.

Once you have it, the coverage is complete: specifications and torques, maintenance intervals, carburetor and fuel system service, engine overhaul with measured limits, shaft final drive, air and conventional suspension, brakes, steering, and an electrical chapter with diagnostics and the full diagram set.
