1990 Yamaha G2-AF (CARB) Service and Repair Manual

Stamped G2 - AF and fitted with a carburettor, the 1990 G2-AF is covered by Yamaha's LIT-19616-G9-93.

Yamaha did not write a book per model here. This one runs from 1985 to 1995 and names thirty-one other machines, including the carburetted G2, G2-A, G2-AB, G2-AC, G2-AD and G2-AG, the 36-volt electric G2 series, and the G9 FLEET MASTER and FLEET CLASSIC line in both drive types.

Contents in brief

• Factory maintenance schedule
• Engine, carburettor and ignition service in sequence
• Clutch, drive, brakes and steering with torque values
• Inspection measurements and service limits
• Wiring diagrams and symptom-led diagnosis

Specifications throughout are the ones Yamaha published when the car was current, which on a machine of this age is usually the only reliable source left for a clearance or a tightening figure. Read the code plate, match G2 - AF, and you have the right reference for the work.
