1990 Audi V8 Quattro Service and Repair Manual
Regular price
$40.99 USD
Unit price
Fits the 1990 V8 Quattro — Base Sedan 4-Door ·
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.7
·
Trusted by 14,000+ mechanics & DIYers
End of preview
Unlock the full manual
Complete repair procedures
Wiring diagrams & schematics
Torque specifications
Full search & bookmarks
$40.99
1990 Audi V8 Quattro Service and Repair Manual
Regular price
$40.99 USD
Unit price
This 1990 Audi V8 Quattro factory service and repair manual is built around the sedan's 3.6L V8 (engine code PT), so the torque values and adjustment procedures inside are the ones Audi specified for this exact powertrain, not a figure borrowed from a smaller-engine sibling.
Engines covered
- 3.6L V8 — DOHC, naturally aspirated, gasoline
Body styles covered
- 4-door sedan
Trims covered
- Base
Known issues on the 1990 V8 Quattro. Three recalls are on federal record for this model year. The first covers the vehicle speed control system: a bushing guiding the cruise control rod can deteriorate over time and bind, impeding the throttle plate's return to idle. The second covers the trunk-mounted jack: an incorrect instruction label for the jack supplied with the vehicle can lead to improper use and jack collapse, risking injury to anyone under or near the car. The third covers the frontal air bag sensor, which does not meet Audi's own durability standard and can malfunction in a way that lets the air bag deploy without warning, risking loss of vehicle control. Owners have filed 8 complaints for the year and no technical service bulletins are logged. The factory diagnostic and repair procedures behind each of those systems are here.
From a cruise control rod that won't return to idle to a proper check of the air bag sensor and jack setup, it keeps you on the OEM procedure and the correct specification for your specific 1990 V8 Quattro.
A BUSHING WHICH GUIDES THE CRUISE CONTROL ROD CAN, OVER TIME, DETERIORATE AND CAUSE THE CONTROL ROD TO BIND.
Consequence
A BINDING CONTROL ROD CAN IMPEDE THE RETURN OF THE THROTTLE PLATE TO ITS FULL IDLE POSITION.
Remedy
DEALERS WILL REPLACE THE CONTROL ROD BUSHING WITH AN IMPROVED VERSION.
INSTRUCTION LABEL IN THE TRUNK OF VEHICLE IS INCORRECT FOR THE JACK SUPPLIED WITH THE VEHICLE.
Consequence
INCORRECT USE CAN RESULT IN THE JACK COLLAPSING, WITHINJURY TO INDIVIDUALS UNDER OR NEAR VEHICLE DURING COLLAPSE.
Remedy
SUPPLY INSERT TO OWNER'S MANUAL NOTING CORRECT USAGE, AS WELL AS A CORRECTED INSTRUCTION LABEL FOR THE TRUNK.
VEHICLE DESCRIPTION: PASSENGER VEHICLES. SOME AIR BAG SENSORS DO NOT COMPLY WITH AUDI'S DURABILITY STANDARDS OVER THE LIFETIME OF THE VEHICLE.
Consequence
IN THE EVENT THE SENSOR SHOULD MALFUNCTION, THE AIR BAG RESTRAINT SYSTEM CAN INADVERTENTLY DEPLOY. DEPLOYMENT OF THE AIR BAG RESTRAINT SYSTEM WITHOUT WARNING COULD CAUSE A DRIVER TO LOSE VEHICLE CONT
Remedy
DEALERS WILL REPLACE THE AIR BAG SENSOR CONTROL MODULE.
No service bulletins
No technical service bulletins on file with NHTSA for the 1990 Audi V8 Quattro.
WHILE DRIVING APPROXIMATELY 60 MPH, IN THE PROCESS OF BRAKING, THE STEERING WHEEL VIBRATES OUT OF CONTROL UNTIL THE SPEED REACHES 25 TO 30 MPH, THEN THE VEHICLE OPERATES CLOSE TO NORMAL. DEALER AND
REAR SPEAKERS MAKE NOISE UPON TURNING RADIO ON. NOISE INCLUDES HUM, HISSING, SQUEAL AND POOP NOISES. ACCORDING TO AUDI, THE SPEAKERS AND AMPLIFIERS IN MY CAR ARE THE ASME AS THOSE IN 1991 AND 1992 V
CRUISE CONTROL WAS ENGAGED, AUTOMATICALLY DISENGAED, HIT RESUME, VEHICLE WENT INTO OPEN THROTTLE POSITION AND WOULD NOT RELEASE, APPLIED THE BRAKES REAL HARD TO STOP VEHICLE.*AK MECHANIC DISENGAGED
THE CONSUMERS VEHICLE DOES NOT FIT WITHIN THE SCOPE OF RECALL 01V-324 DUE TO THE VIN, THE CONSUMER FEELS THE VEHICLE IS SUBJECT TO THE SAME RISK OF FAILURE AND FIRE.
WHILE DRIVING DRIVER'S SIDE AIR BAG DEPLOYED WITHOUT BEING IN AN ACCIDENT. *AK
THE ROTORS HAVE TO BE REPLACED EVERY (10,000-15,000) MILES BECAUSE OF WARPING. BECAUSE OF THE WARPED ROTORS, WHEN BRAKING, THE VEHICLE GOES INTO A UNCONTROLLABLE SHAKING VIRBRATION. IN THE LAST 2 1/2
THE DRIVER WAS ATTEMPTING TO PASS ANOTHER VEHICLE ON THE HIGHWAY, WHEN THERE WAS AN INCREASE IN ACCELERATION. THE THROTTLE WAS STUCK IN THE OPEN POSITION. THE CONSUMER SAYS THAT IT WAS DUE TO THE CRU
NHTSA ALREADY HAS A DEFECT NOTED AS #01V324000 - THIS NOTICE IS TO ADVISE THE CONDITION EXISTS ON 1990 MODELS NOT JUST THE 1991 AS LISTED IN THE NHTSA REPORT. MY SPEAKERS HAVE FAILED JUST AS THE REPO
