1988 Yamaha MOTO-4 200 Service and Repair Manual

Written to cover four model years at once, Yamaha LIT-11616-YF-20 includes the 1988 MOTO-4 200, model code YFM200DXU, along with the 1985 to 1987 machines and the MOTO-4.

The value of a shared book is that it distinguishes the years where it matters and repeats nothing where it does not. Specification tables and wiring pages carry the year notes; the procedures themselves are common.

Typical jobs it walks you through

• Valve clearance and ignition adjustment
• Carburettor cleaning, jetting and float setting
• Brake service with shoe and drum limits
• Drive train inspection and final drive service
• Charging and starting circuit fault tracing

Torque tables and fluid capacities sit at the front, with exploded views throughout for parts identification. Confirm YFM200DXU on the frame label, then work from the tables that match it.
