1986 Yamaha VMAX Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Two factory books apply to the 1986 VMAX, because two model codes do: VMX1200S and VMX540K. The part numbers are LIT-11616-VM-13 and LIT-12628-00-80, and the coverage between them stretches from 1985 to 2000.

Start by reading the code off your machine. It decides which of the two volumes carries your specifications, and with a sixteen-year span behind these numbers that distinction is not a small one.

The material itself is the usual factory standard. Engine work is given as a disassembly sequence with measurement points, wear limits and reassembly torque. Fuel system, lubrication, drive components, chassis and suspension each have their chapter, and the electrical sections include wiring diagrams together with the resistance and voltage checks needed to test components in place. Troubleshooting is written around symptoms.
