1986 Yamaha G1-AM (36V - DC MOTOR) Service and Repair Manual

Electric G1 cars from 1986 are listed as model code G1-EM, and manual LIT-11616-G1-83 is the Yamaha part number that documents them.

This is the wide-coverage volume: six model years between 1982 and 1989, thirteen variants, carbureted and 36-volt DC motor cars together.

The electrical material is what matters on this machine. Motor service, contactor and control circuit testing, the charging system and the complete factory wiring diagram are all present, with the readings Yamaha expected at each test point. Mechanical chapters then cover the rear axle, brake adjustment and service, steering and front suspension, each with wear limits and tightening torques. The maintenance schedule at the front sets the intervals. Between the diagram and the specified values, most faults on these cars can be isolated without guesswork.
