1985 Plymouth Caravelle Service and Repair Manual
- Digital manual
- Matched to your model
- Pay once, yours to keepPay once
- 180-day refund
This factory service and repair manual for the 1985 Plymouth Caravelle serves the four-door sedan in two trims, Base and SE. Three of the four gasoline engines used a single overhead camshaft: the 2.2L inline-four in naturally aspirated and turbocharged form, both 135 cubic inches, and a 2.6L four at 156. The fourth is the 5.2L V8, an overhead-valve design displacing 318 cubic inches. The manual carries procedures, specifications and torque values for those engines and their fuel, ignition and cooling systems, with wiring diagrams for the sedan's electrical system.
Engines covered
- 2.2L inline-four (135 cu in) — SOHC, naturally aspirated, gasoline
- 2.2L inline-four (135 cu in) — SOHC, turbocharged, gasoline
- 2.6L inline-four (156 cu in) — SOHC, naturally aspirated, gasoline
- 5.2L V8 (318 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 4-door sedan
Trims covered
- Base
- SE
Known issues on the 1985 Caravelle. The 1985 Caravelle has 2 recalls on record, and both involve fuel that could escape under the hood. In the first, certain 1985 Caravelle vehicles with a particular engine could leak fuel in cold weather where the supply hose joins the pressure regulator and the fuel rail; the regulator was moved and a reshaped hose with new routing installed. The second covered certain 1985 Caravelle cars with a particular engine, 53,000 vehicles, whose hose clamp at the regulator might not have been tightened enough, risking a leak and an engine bay fire. One complaint concerns the gasoline fuel system. Fuel system procedures, specifications and torque values are part of this manual.
