1984 Chevrolet Citation II Service and Repair Manual
This factory service and repair manual for the 1984 Chevrolet Citation II is a two-engine book. The 2.8L overhead-valve V6 of 173 cubic inches and the 2.5L overhead-valve inline-four of 151 are both naturally aspirated and both run on gasoline, and either could be found in any of three bodies: a two-door sedan, a four-door hatchback and a two-door hatchback. Base and X-11 are the trims. Anyone servicing one of these cars begins by identifying the engine, because the specifications diverge from that point on.
Engines covered
- 2.8L V6 (173 cu in) — OHV, naturally aspirated, gasoline
- 2.5L inline-four (151 cu in) — OHV, naturally aspirated, gasoline
Body styles covered
- 2-door sedan
- 4-door hatchback
- 2-door hatchback
Trims covered
- Base
- X-11
Known issues on the 1984 Citation II. The federal record shows two recalls for this year, both about fuel escaping where it should be contained. In one, a replacement fuel filter does not seal properly at its connection, and leaking gasoline can ignite. In the other, the fuel feed pipe connection at the throttle body injection unit can leak, with fire under the hood able to reach the passenger compartment and burn occupants. Eight owner complaints are on record, the fuel system drawing three of them and steering and speed control one apiece. Fuel line, throttle body and steering service are all documented here.
