1982 Yamaha G1 (36-VOLT DC MOTOR) Service and Repair Manual

From 1982 the G1 manual changes. Yamaha issued LIT-11616-G1-83 for the later cars, and the 1982 36-volt car in it is model code G1-E3. If you have been working from the earlier book, this is the one that matches your machine.

Thirteen variants are documented here across the 1982, 1983, 1984, 1985, 1986 and 1989 model years, electric and carbureted together: the G1-A3, the AM series, the AMD, the E3 and the EM cars.

What it gives you

Measured specifications instead of approximations. Motor and control circuit tests with expected readings, brake and axle service with clearances, steering and front end adjustment, torque tables, the periodic maintenance schedule, and the factory wiring diagram for the 36-volt system as built.
