1982 Volkswagen Caribe Service and Repair Manual

This factory service and repair manual for the 1982 Volkswagen Caribe covers a hatchback built with either four doors or two. Two SOHC inline-fours, both naturally aspirated, were listed: a 1.6L diesel of 97 cu in and a 1.7L gasoline engine. The three trims are Base, Diesel and GL. Procedures, specifications, torque values, wiring diagrams and diagnostics apply to the engine, fuel system, ignition, cooling, transaxle, brakes, suspension, steering, electrical system and body.

Engines covered

• 1.6L inline-four (97 cu in) — SOHC, naturally aspirated, diesel
• 1.7L inline-four — SOHC, naturally aspirated, gasoline

Body styles covered

• 4-door hatchback
• 2-door hatchback

Trims covered

• Base
• Diesel
• GL

Known issues on the 1982 Caribe. Diesel and gasoline engines on the 1982 Caribe share a single overhead camshaft layout but differ in fuel delivery and ignition. The manual gives fuel system procedures and diagnostics. Cooling system specifications and engine torque values sit beside procedures for the transaxle and drivetrain. Brakes, suspension and steering are included, and wiring diagrams cover the electrical system of the hatchback in Base, Diesel and GL trim.
