1978 Yamaha XS500 Service and Repair Manual

XS500E is the code on the 1978 XS500, the last model year inside Yamaha's LIT-11616-01-46, a service manual that begins with the 1975 machines.

Later bikes gain something from sitting at the end of a multi-year book: the changes made across the run are already recorded, attributed to the codes they apply to, so the figures you work to are the ones the factory settled on by 1978.

Coverage runs from routine adjustment through complete overhaul. The engine chapters give disassembly order, measurement points, service limits and reassembly torque; the chassis chapters cover forks, rear suspension, wheels and brakes; the fuel chapter handles carburetor adjustment and synchronising; the electrical chapter provides test values alongside diagrams of the harness as built. Troubleshooting is written from the symptom back to the cause.

Check that your frame or engine reads XS500E before ordering.
