1974 Yamaha RD200 Service and Repair Manual

$18.00 USD
Digital manual — nothing ships
Matched to your exact vehicle
Money-back guarantee, pay once
4.5 · Trusted by 800+ mechanics & DIYers
Buy 2+ manuals, save 20% Discount applied automatically at checkout
20% off

Unlike the later RD200 books, this one stands alone: LIT-11613-97-00 was written for the 1974 model year only, so every figure on the page belongs to the RD200A. There is no cross-model column to misread.

The chapters follow factory order. Routine maintenance and adjustment come first, then the engine comes out of the frame and is taken through the top end, the crank assembly, the clutch and the gearbox with torque values and service limits given at each step. Carburettor work, ignition timing and the charging system follow, and the chassis section deals with forks, swingarm, wheels, brakes and cables.

For a bike this age the troubleshooting pages tend to earn their keep more than the teardown ones, and the wiring diagram is worth having in front of you before you cut into a harness.

Confirm RD200A and part number LIT-11613-97-00 to be certain this is the right book for your machine.
